CANTEK UpCut Saw 15 HP

The Cantek PCS24L (also referred to as PCS24 or PCS24L-230 for the 230V version) is a 24-inch pneumatic cut-off saw designed for industrial crosscutting operations. Here are its key specifications:

Key Specifications:

• Blade Diameter: 24 inches (can accommodate 20" to 24" blades)
• Motor: 15 HP
• Arbor Diameter: 1 inch
• Blade Speed: 2400 RPM
• Cutting Capacity (Thickness x Width):2" x 21"
• 4" x 19"
• 6" x 15"
• 7" x 8" (some sources also list 8" x 8" for certain configurations)
• Cycle Speed: Up to 40 strokes per minute (some sources state up to 95 strokes per minute, indicating adjustable speeds)
• Cycle Operation: Air/Mechanical, typically controlled by a pneumatic foot pedal (optional dual push-button control available)
• Table Size: 45.3" x 26"
• Dust Exhaust: 2 x 4" diameter ports
• Air Requirements: 27.5 CFM
• Electrical Requirements:230V, 3-phase, 60Hz: 42 Amps
• Net Weight: 1058 lbs
• Gross Weight: 1433 lbs
• Machine Dimensions (LxWxH): 40.2" x 45" x 55"
• Operation Hand: Available in Left Hand (PCS24L) or Right Hand (PCS24R) configurations.

Key Features:

• Large Capacity Crosscutting: Designed for high-production environments.
• Adjustable Cutting Stroke: Allows for optimization of cutting speed and quality based on material.
• Robust Construction: Features a precision-ground cast iron table surface for high cutting accuracy.
• Material Clamp: Easily adjustable for variations in workpiece thickness.
• Safety Features: The saw blade is fully enclosed in the cabinet and covered by the clamp during operation. Emergency stop button is also included.
• Control Options: Standard pneumatic foot pedal control.

This saw is built for precision, speed, and safety in industrial woodworking and similar applications.

Comes with 3 extra blades.
