Morbark StacTrac 1000

The Morbark Stac-Trac is engineered for efficient sorting and stacking of lumber, ties, and cants, streamlining operations that would otherwise require multiple workers on a green chain.

This unit excels at lifting and stacking challenging timbers, minimizing labor expenses and reducing injury risks linked to manual material handling. Its user-friendly design enables a single operator to effortlessly manage travel along the track, control the lumber grapple, adjust the extension and vertical movement of the boom, and operate the unit's swinging motion, all from a comfortable and adjustable operator's seat.

Specifications & Details

Specifications

SPECIFICATIONSUSMETRIC1000 Stac Trac Specifications: Power15-hp electric11.2-kW electric Track Speed 211 fpm 64.3 m/min Grapple Opening1.375" – 18" 3.5 cm – 45.7 cm Weight 4,700 lb 2,131 kg Boom Swing360 degrees Manpower Required one operator Standard Track 30' with Nylotube electric cable carrier 9.1 m

Lifting Capacity1,480 lb 671 kg

This machine is currently running. It will pick up a 7" x 9" x 16' long timber with no issues.
